Guide Sensmart TR 630

Original price was: $3,099.00.Current price is: $2,799.00.

Guide Sensmart TR 630 35MM Thermal Riflescope 640×480 Thermal Core 1024×768 AMOLED HD Display 50 Hz

Click to Email Questions +

Call (832) 363-3783 for availability

Description

Guide Sensmart TR 630


Guide Sensmart TR 630 Thermal Scope Ships Free!

All new Guide Sensmart TR 630 Thermal Scope is Guide Sensmarts Flagship 35MM thermal Scope with high resolution 640X480 Thermal Core and .39 inch full color AMLOED 1024×768 HD Display. It’s high resolution thermal core, vivid HD display, 35MM F1 HD lens and fast 50 Hz refresh rate, provide super crisp image detail with excellent contrast in all weather conditions. It has a base magnification of 2.0X with a crisp digital zoom out to 16X and has a thermal detection range of 1400 meters. The GS TR 630 series thermal is IP67 rated, making it perfect for rainy and dusty weather conditions. Also, Zeroing this TR 650 is super easy with its one touch screen freeze option, simply shoot, take a picture of the screen, then move reticle to the bullet hole, hit save and you are zeroed. Furthermore, the TR650 has a huge color palette, offering White Hot, Black Hot, Red Hot, Green Hot, Iron Red and Blue Hot. This wide range of color palette’s makes finding the perfect color for different weather and hunting conditions easy.

This Guide Sensmart TR 630 Thermal Scope comes with one rechargeable 18650 battery and charger, the 18650 battery provides 8 hours of continuous use. Furthermore, it also has a USB C for use with optional external battery packs. The TR 630 has internal video recording, picture mode, picture n picture and screen mirroring via its on board Wi-Fi. Simply down load the Guide Sensmart “TargetIR APP” to your mobile device – smart phone, then turn on the thermals on board Wi-Fi, once the Wi-Fi is on, then select the thermal it in Bluetooth menu of your mobile device and input default code 12345678 to connect. Sensmart also offers a optional (S600LRF Range finder) with precise 600 meter detection range that can be added to any TR Series thermal scope. This is perfect for hunters that would like to add a LRF unit at time of purchase or later on down the line if needed. Xtreme Guns and Ammo carries the full line of Guide Sensmart Optics in Stock. Shop Online anytime, or call the Guide Sensmart Pros at 832-363-3783, or chat with the Guide Sensmart Experts during regular store hours, for answers to all of your Guide Sensmart Thermal questions and needs.

Guide Sensmart TR 630 (Specifications)

  • Part Number: TR630
  • UPC: 6970883550951
  • Type: Uncooled VOx Infrared Detector, 8 to 14μm
  • Max Resolution: 640×480@12μm
  • NETD: 30mK
  • Frame Rate: 50 Hz
  • Magnification: 2.0x-16x
  • Objective Lens: 35mm, F1.0
  • Field of View: 12.38° x 9.38°
  • FOVm@100: 22×16
  • Detection Range: 1400m/yd
  • Display: 0.39 inch AMOLED 1024×768
  • Color Palettes: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot
  • Eyepiece: Exit pupil distance 48mm; Diopter+/- 4; Zoom 14x
  • WIFI: 2.4G
  • Interface: USB Type-C
  • Tube Diameter: Standard 30mm
  • Recording Function: Photo/Video
  • Memory Capacity: 32GB
  • Battery Type: Single, replaceable 18650 battery
  • Operating Time: 8 Hours
  • Operating Temp: -30C to 50C/-22F to 122F
  • Shock: 800G at 1 ms half sine pulse (as per IEC60068-2-27)
  • Encapsulation: IP67
  • Weight: 540 grams/19.05ounces
  • Size: 208x88x66mm/8.19×3.46×2.60inches
  • Included: Device, Sight Base, Type C cable, 5V2A Adapter, 18650 Battery, Battery Charger, Lens Cover, Eye Mask, Quick Start Guide, Warranty.
  • Optional: Dovetail Guide, Bluetooth Remote Control, Laser Rangefinder
